Product Description
Single‑rail guided rover cart is a rail‑guided‑vehicle (RGV) material‑transfer cart travelling on a single linear guide rail. Driven by servo motor and rack‑pinion drive system, it performs reciprocating shuttle movements between fixed stations along single‑rail tracks. It features simple track‑laying requirements and cost‑effective investment. It is mainly used for fixed‑point pallet‑transfer between silo stations, processing equipment and buffer stations inside manufacturing workshops, suited for medium‑weight pallet circulation on straight‑line fixed‑routes.
Single‑rail RGV performance is highly dependent on route layout and pallet weight. Drawing‑based manufacturing lets us customize travel length, payload and number of stop stations based on customer‑workshop‑station‑layout drawings to guarantee stable positioning accuracy for each material‑transfer station.
Technical Parameters
|
Parameter Item |
Specification |
|
Power Supply |
AC220V |
|
Total Power |
1.5kW |
|
Track Type |
Single-rail Straight Line |
|
Drive Mode |
Servo Drive + Encoder Positioning |
|
Positioning Accuracy |
±0.25mm |
|
Load Capacity |
Max350kg(Customizable) |
|
Walking Speed |
adjustable |
|
Working Temperature |
-10°C to 45°C |
|
Control Mode |
PLC + Touch Screen Fully Automatic |
|
Communication Interface |
Standard I/O signals |
Applications
Application 1
Straight‑line multi‑station pallet circulation in CNC workshops. Shuttles full and empty pallets between multi‑layer silos and multiple processing‑stations along fixed single‑rail routes for mass‑production material logistics.
Application 2
Machine‑tool‑to‑buffer‑station material transfer. Transports loaded and empty pallets between processing‑cells and intermediate buffer‑stations to reduce manual trolley‑transport workload.
Application 3
Cost‑limited fixed‑route intra‑factory‑logistics upgrades. Compared with dual‑rail and loop‑track RGV, single‑rail solutions lower track‑construction costs for simple straight‑line material‑transport demands.
Customization
- Custom effective travel distance, rated payload and docking‑station quantity.
- Custom pallet‑positioning fixtures mounted on cart platform.
- Custom IO interlock‑signal logic for docking with silos and production‑equipment.
- Optional power‑supply‑mode customization (cable / sliding‑contact‑line).
Packaging & Transportation
Vehicle‑body wrapped with anti‑scratch plastic film. Electrical‑components packed inside shock‑proof cartons. Rail‑segments are packed inside steel‑reinforced export‑wooden crates. Pre‑shipment running‑and‑positioning tests are completed before shipment for sea‑land‑international‑freight.
FAQ
Q1. Can single‑rail guided rover cart travel along curved routes?
Answer. Standard single‑rail version only supports straight‑line reciprocating travel. Curved‑route applications require circular‑track‑RGV solutions.
Q2. What civil‑works are needed for installation?
Answer. Flat reinforced‑concrete floor for rail‑fixing is required. We will provide rail‑laying drawings for customer‑site preparation.
Q3. Can it automatically dock with multi‑layer silos?
Answer. Yes, automatic‑station‑docking can be achieved with custom IO‑signal‑interlock‑configuration.
